TACTICAL electronic hearing protectors COMMS

Product detailed description

TRUE 360° SITUATIONAL AWARENESS
Each ear cup is equipped with two omnidirectional microphones.
Left and right channels are processed independently to deliver realistic spatial awareness.
5 ambient sound amplification levels

dedicated mode for use with earplugs
Automatic impulse suppression at (82 ± 3) dBSPL
Reaction time ≤ 10 ms
Maintains environmental awareness even during high-intensity fire.

MODULAR CONNECTIVITY
The headset cable can be configured with virtually any professional connector type.
Common connector families:
NEXUS TP
NEXUS AP
ODU AMC
NATO / U-174 / TP-120 and others upon request
Cable configuration options:
Fixed or detachable
Left and/or right side mounting
Fully adaptable to the user’s communication system.

RADIO INTEGRATION
Supports integration with a wide range of radio systems:
Tactical radios
Two-way / walkie-talkie systems
Professional communication systems (including MATRA-type systems)
Configuration is tailored to the specific operational environment.

MICROPHONE OPTIONS
Boom microphone options include:
Fixed or detachable configuration
Left or right side mounting
Dynamic or electret microphone type
Direct connection of a CBRN mask microphone (e.g. TAPRM) is supported.

PTT & CONTROL
Optional PTT button integrated directly on the headset
Compatibility with external PTT units
RED DOT ONE proprietary system:
PCCH – Personal Communication and Control Hub
Available in multiple configurations:
Fixed or detachable cable versions
Integration with radios
Intercom systems
External microphones
Additional communication devices per customer specification
PCCH enables centralized communication control.
PROTECTION & DURABILITY
EN 352 certified
PPE Regulation (EU) 2016/425
EMC Directive 2014/30/EU
RoHS Directive 2011/65/EU
IP67
Operating temperature: -20 °C to +60 °C
UL 94 – min. V2
Developed for demanding professional environments.
MODULAR. SCALABLE. MISSION-READY.
